ESC for RC Aircraft
This series of products are developed for none-hall direct current brushless motors.They have excellent commonality,not only can be used for fixed-wing aircrafts but also for helicopters.The products have perfect function, specially 4 seconds very soft start performance which is very suitable for helicopters and the brake performance is very suitable for folding propeller aircrafts.Several parameters can be set through program card or transmitter. | (1) XP serial for plane,BEC is Linear Mode：
(2) XP serial for plane,BEC is Switch Mode
This serial ESC have the same function as the ESC of linear mode BEC. The BEC adopts high efficiency switch mode. Even input is high voltage, BEC still can output stable 3A current, so it can drive more servos and self-heating of BEC is small. This serial is suitable for helicopters with more servos.
|
Model |
Continuous Current |
Li-XX |
BEC |
Program card programming |
transmitter programming |
|
XP-35A-SW |
35A |
2-5 |
3A/5V |
Yes |
Yes |
|
XP-40A-SW |
40A |
2-5 |
3A/5V |
Yes |
Yes |
|
XP-45A-SW |
45A |
2-5 |
3A/5V |
Yes |
Yes |
|
XP-50A-SW |
50A |
2-5 |
3A/5V |
Yes |
Yes |
|
XP-60A-SW |
60A |
2-6 |
3A/5V |
Yes |
Yes |
|
XP-80A-SW |
80A |
2-6 |
3A/5V |
Yes |
Yes | |
